Authorised UK DistributorFuel Safe
Description
Fuel Safe's Race Safe® line of fuel cells offers top shelf safety at a bargain basement price. Built to the same specifications as our Enduro® line of fuel cells, but lacking an FIA certification.
All Race Safe® racing cells come complete with:
- Highly durable Race Safe® bladder
- Full safety foam baffling, minimises fuel slosh and the potential for an explosion
- SF6X10E fill plate comes standard with a -8 pickup (plumbed to the right rear of the cell), -8 return, -8 rollover vent valve, high quality threaded aluminium fill cap and a sending unit provision.
- Aircraft grade nut ring and gasket
- Fuel pickup assembly, factory installed
- 5 year manufacturer warranty
Available sizes (Race Safe range):
| RS105 | 5 gal | 13.125" x 13.125" x 8.125" (4x6 plate, -6 fittings) |
| RS108 | 8 gal | 20.125" x 15.5" x 7.5" |
| RS108B | 8 gal | 20.125" x 12.125" x 8.625" |
| RS112 | 12 gal | 20.188" x 17.313" x 9.188" |
| RS115 | 15 gal | 25.188" x 17.313" x 9.188" |
| RS122A | 22 gal | 33.625" x 17.5" x 9.063" |
| RS122B | 22 gal | 24.75" x 16.625" x 13.313" |
| RS125 | 25 gal | 25.5" x 17.313" x 14" |
| RS132A | 32 gal | 33.5" x 17.313" x 14.125" |
| RS132B | 32 gal | 25.5" x 17.25" x 18" |
Specifications
- Brand
- Fuel Safe
- SKU
- VMEP-C0C7A96B-8USGALLON30LITRES-NOCAN
